AUTODESK INVENTOR

Trial Projects

Photorealistic Visualization

Render a front loader

In Inventor, click the ‘Projects’ icon in the ribbon. Navigate to where you saved the project files and select Front loader.ipj. Then open Front Loader.iam. To begin go to the ‘View’ tab in the ‘Appearance’ panel click on ‘Visual Style’. Select ‘Technical Illustration’ from the drop down list. Your model should look like the technical illustration style as shown in the image above. Next select ‘Grid Light’ and in the drop down list click on ‘Grey Room’. _2.

3._ PART 1: PHOTOREALISTIC VISUALIZATION

Notice that the edge lines are currently displayed as the color. Next go to the ‘Tools’ tab and select ‘Application Option’. The ‘Application Options’ dialog box appears select the ‘Display’ tab and under ‘Appearance’ click the ‘Settings’ button. The ‘Settings’ dialog box appears, under ‘Model Edges’ se- lect ‘One Color’ and make sure that the color swatch is set to ‘Black’, as shown in the image above. _10.

11._ PART 1: PHOTOREALISTIC VISUALIZATION

Select ‘OK’ on the ‘Settings’ dialog box and the ‘Application Options’ dialog box. Notice that all the lines are now black. Select the ‘Application Options’ button and select on the ‘Colors’ tab. Make sure that ‘Presentations’ is highlighted and under ‘Background’ select ‘1 Color’. The Presentation 1 Color scheme default is color white. Select ‘OK’. Notice how white the background color is now. Next you will apply some shadows. Go to the ‘View’ tab and in the ‘Appearance’ panel select on the ‘Shadows’ button. _14.

15._ PART 1: PHOTOREALISTIC VISUALIZATION

Open the assembly Front Loader.iam. Begin by going to the ‘View’ tab and under the ‘Appearance’ panel select ‘Visual Style’. In the drop down list select ‘Shaded with Edges’. Notice that colors have now been added to the part model. Next turn on the ‘Ground Plane’ in the ‘Appearance’ panel by clicking a check in the ‘Ground Plane’ box. _22.

23._ PART 2: PHOTOREALISTIC VISUALIZATION

Notice that the ground is set way below the part model. On the ‘Ground Plane’ drop down menu select ‘Settings’. The ‘Settings’ dialog box appears, select ‘Manual Adjustment’ under the ‘Position and Size’. Then using the mouse cursor drag in the Z direction to move the ground plane up to the bottom of the Front Loader’s tires. Make sure just the bottom of the tires touch the ground plane. _26.

27._ PART 2: PHOTOREALISTIC VISUALIZATION

When finished select ‘Save’ and ‘Close’. Notice the difference in size between the environment and the Front Loader. Next you will need to add more shadows. Go to the ‘Shadows’ in the ‘Appearance’ panel and select ‘Ground Shadows’. Next select ‘Settings’ to make changes to the shadows. Select the ‘Shadows’ tab. Under ‘Lighting Direction’ select 45-Degrees Left from the drop down list. Then set the ‘Softness’ to 60. Finally set the ‘Ambient Shadows’ to 60. Select ‘Save’ and ‘Close’. Notice the difference of the image with the shadows. _34.

35._ PART 2: PHOTOREALISTIC VISUALIZATION

Next, to create the realistic rendering the entire part model must be loaded, to do so select ‘Load Full’ in the ‘Express’ panel. This will allow the ‘Realistic’ option to be available in the ‘Visual Style’ drop down list. Next select ‘Visual Style’ in the ‘Appearance’ panel and in the drop down list select ‘Realistic’. Notice how the image has no line edges. Next you will begin the realistic rendering by selecting ‘Ray Tracing’ in the ‘Appearance’ panel. _38.

39._ PART 2: PHOTOREALISTIC VISUALIZATION

Autodesk, Autodesk Inventor, and the Autodesk logo are registered trademarks or trademarks of Autodesk, Inc., and/or its subsidiaries and/or affiliates in the USA and/or other countries. All other brand names, product names, or trademarks belong to their respective holders. Autodesk reserves the right to alter product offerings and specifications at any time without notice, and is not responsible for typographical or graphical errors that may appear in this document. © 2017 Autodesk, Inc. All rights reserved.
