COMP 310:
Operating Systems
Lecture 6: Semaphores
September 17, 2004
Christine Alvarado
Today’s Topics
OS Support for Synchronization
Semaphores review
Monitors
Last time
Semaphores
Review: Topics so Far
Process 1 Process 2 S1 S2^ S Thread 1 Thread 2 Thread 3 Thread 1 Thread 2
Readers/Writers
An object is shared across many threads.
Some threads want to read it, others want to write to it
Any number of readers can read at the same time
When a writer writes, there can be no other readers or
writers accessing the object
What do we need to keep track of?
how many are reading who wants to write who wants to read
Readers/Writers
// keep track of how many // reading int read_count = 0; // keep track of writing or // reading and who wants to // read/write Semaphore w_or_r = 1; Semaphore mutex = 1; writer { wait(w_or_r); write signal(w_or_r); } reader { wait(mutex); read_count++; if (read_count == 1) { wait(r_or_w); } signal(mutex); Read wait( mutex ); read_count--; if (read_count == 0 ) { signal(w_or_r); } }
2 Bounded Buffer There is a set of resource buffers shared by producer and consumer threads Producer inserts resources into buffer set if not full Consumer removes resources if buffer set not empty They execute at different rates
They execute independently
Consumer just looking in buffer to consume and producer
just writes to buffer
What semaphores will we need? What do we need to keep track of? make sure not writing at same time make sure there’s something to read make sure there’s room to write Leads to one mutex and 2 counting Bounded Buffer Implementation Pair up and work on this problem Three semaphores:
mutex
empty (counting, starts at N)
full (counting, starts at 0)
You need two threads:
Producer and consumer
Producer adds to buffer if not full, otherwise waits
Consumer takes from buffer if empty, otherwise waits
Remember you can’t modify the buffer at the same time!
do { produce an item wait(empty); wait(mutex); add nextp to buffer signal( mutex ); signal( full ); } Semaphore mutex = 1; Semaphore full = 0; Semaphore empty = N; do { wait(full); wait(mutex); remove an item signal(mutex); wait(empty); consume the item } What if there were more than one producer or consumer What if we switch around mutex and full? (Deadlock) Semaphores Summary Semaphores can be used to solve any of the traditional synchronization problems They have some drawbacks:
They are shared global variables
No connection between semaphore and data
Used both for CS and coordinating… confusing
No control! Can we use them wrong? Yes!
Sometimes hard to use and prone to bugs.
Programming language support for synchronization
