1

Lecture 3:

The relational model

www.cl.cam.ac.uk/Teaching/current/Databases/

E.F. Codd

Today’s lecture

• What’s the relational model?
• What’s SQL?
• How do we create databases in SQL?
• How do we convert E/R models to a relational model?
• How do we enforce real-life constraints in a relational database?

The relational model: Early

history

• Proposed by E.F. Codd (IBM San José) ~
  • Prior to this the dominant model was the network model (CODASYL)
• Mid 70’s: prototypes
  • Sequel at IBM San José
  • INGRES at UC Berkeley (M. Stonebraker)
  • PRTV at IBM UK
• 1976-: System R at IBM San José
  • Transactions (J. Gray et al.)
  • Query optimiser (P. Selinger et al.)
  • Extended -testing (Boeing et al.)
• 1978/9-: CODD at Cambridge Computer Lab
  • Extended relational algebra query language (K. Moody)

5

The relational model: Basics

• A relational database is a collection of relations
• A relation consists of two parts:
  • Relation instance : a table, with columns and rows
  • Relation schema : Specifies the name of the relation, plus the name and type of each column
• Can think of a relation instance as a set of rows or tuples

Examples

• Relation instance

sid name login^ age 1001 Myleene MK 23 1002 Danny DF 22 1003 Noel NS 21 1004 Suzanne SS 20 1005 Johnny JS 23

Field names

Fields

Tuples

Relational terminology

• A domain is a set of values. All domains in a relation must be atomic (indivisible)
• Given a relation R=R(A 1 : 1 , …, An: (^) n), R is said to have arity (degree) n
• Given a relation instance, its cardinality is the number of rows - For example, in Students, cardinality= (arity=4)

Keys

• Given a relation R=R(A 1 : 1 , …, An: (^) n) a (candidate) key is a subset of fields K {A 1 , …, An} that acts as a unique identifier for each tuple in the relation instance
• We annotate the schema accordingly, e.g.

R=R(A 1 : 1 , …, An: (^) n)

SQL

• SQL is the ubiquitous language for relational databases
• Standardised by ANSI/ISO in 1992: SQL/
• Part of SQL is a Data Definition Language (DDL) that supports the creation, deletion and modification of tables

Removing and altering tables

• We can delete both the schema information and all the tuples, e.g. DROP TABLE Students;
• We can alter existing schemas, e.g. adding an extra field ALTER TABLE Students ADD COLUMN matric INTEGER;

Adding and deleting tuples

• Can insert tuples into a table, e.g. INSERT INTO Students(sid,name,login,age) VALUES (“1006”, “Julia”, “jfg”, 21);
• Can remove tuples satisfying certain conditions, e.g. DELETE FROM Students WHERE name=“Myleene”;

From E/R diagrams to relations

• The E/R model is convenient for representing the high-level database design
• Given an E/R diagram there is a reasonably straightforward method to generate a relation schema that corresponds to the E/R design

Entity types to relations

• A (strong) entity type maps to a relation schema in the obvious way, e.g.

is mapped to the relation schema

Employees(NI: 1 , Name: 2 , dob: 3 )

NI Name dob

Employees

Example

is mapped to the relation schema:

Works_in(NI: 1 , DID: 2 , since: 3 )

Works_in

NI Name dob

Employees

DID dname budget

Departments

since

M (^) N

Recursive relationship sets

• Just pick appropriate field names! E.g.

is mapped to

Reports_to(sup_NI: 1 , sub_NI: 1 )

Employees

Reports-to

NI

name (^) dob

supervisor subordinate
