2 Drawing in AutoCAD Questions and Answers
A circle may be defined by its center and... - ANS-radius or diameter
A place that gives you quick access to commands that are frequently turned on and off -
ANS-status bar
A polygon that is drawn on the inside of a circle is said to be - ANS-inscribed
A polygon that is drawn on the outside of a circle is said to be - ANS-circumscribed
A relative coordinate is indicated by placing what symbol before your coordinate? -
ANS-@
A relative coordinate is measured relative to the... - ANS-last point entered
After selecting several objects to erase, what command would you type if you wanted to
remove an object(s) from the selection set? - ANS-remove
An absolute coordinate is measured relative to the... - ANS-origin
An arc may be defined by its start, end, and... - ANS-radius, direction, or angle
Clicking and dragging the mouse from left to right produces a... - ANS-standard window
Clicking once on an object while not currently in a command accesses the... - ANS-grip
boxes
Clicking, holding, and dragging the mouse produces a... - ANS-lasso window
Object snaps not only speed up the drawing process, you cannot draw _______ without
them unless you enter coordinates. - ANS-accurately
The command that is used to select your unit of measure and precision - ANS-units
The command that is used to set your paper size - ANS-limits
The command used to make a line longer by a prescribed length - ANS-lengthen
The grip box options may be accessed by __________ on one of the boxes. - ANS-right
clicking
The most common ways of accessing AutoCAD's commands are through the... - ANS-
application button, ribbon panels, command window, shortcut menus, and status bar
